GDS Power + Data Dock with Latch for Zebra ET4x 10″ Tablet Ram Mounts RAM-GDS-DOCKNLL-ZE21PDU
306,24 € Iva Inclusa
Esaurito
DESCRIZIONE IN INGLESE:
For frequent docking and undocking of the Zebra ET40 & ET45 10″ tablets wrapped in an IntelliSkin protective sleeve, this form-fit GDS vehicle dock (RAM-GDS-DOCKNLL-ZE21PDU) features a top latch design for securing the tablet without wear and tear on the dock itself. Power is provided via a USB Type-C connector and allows you to keep the device charged through the pogo pin contacts when the IntelliSkin-wrapped ET4x 10″ is docked. A single USB Type-A pigtail connector is provided for adding one additional input device. The dock also includes space in the back for tablet add-ons such as the Zebra Expansion Back, PowerPack Battery, and GDS Ergo accessories like the GDS Roto-Mag and GDS Hand-Stand. To mount this dock, pair any RAM 4-hole AMPS or 75mm x 75mm VESA pattern bases for attaching a double socket arm in order to complete your mounting solution. Take the solution a step further by taking advantage of the GDS Ecosystem and the built-in 2-hole mounting plate compatible with RAM 2-hole diamond base for additional device mounting such as a phone, scanner, printer, or any other handheld device. Always Protected. Always Connected.
For frequent docking and undocking of the Zebra ET40 & ET45 10″ tablets wrapped in an IntelliSkin protective sleeve, this form-fit GDS vehicle dock (RAM-GDS-DOCKNLL-ZE21PDU) features a top latch design for securing the tablet without wear and tear on the dock itself. Power is provided via a USB Type-C connector and allows you to keep the device charged through the pogo pin contacts when the IntelliSkin-wrapped ET4x 10″ is docked. A single USB Type-A pigtail connector is provided for adding one additional input device. The dock also includes space in the back for tablet add-ons such as the Zebra Expansion Back, PowerPack Battery, and GDS Ergo accessories like the GDS Roto-Mag and GDS Hand-Stand. To mount this dock, pair any RAM 4-hole AMPS or 75mm x 75mm VESA pattern bases for attaching a double socket arm in order to complete your mounting solution. Take the solution a step further by taking advantage of the GDS Ecosystem and the built-in 2-hole mounting plate compatible with RAM 2-hole diamond base for additional device mounting such as a phone, scanner, printer, or any other handheld device. Always Protected. Always Connected.
CODICE PRODOTTO: RAM-GDS-DOCKNLL-ZE21PDU
LINEA PRODOTTO: GDS Tech
TIPO PRODOTTO: Components
QUESTO SUPPORTO E’ COMPATIBILE CON I SEGUENTI DISPOSITIVI
– Zebra ET40 10″ Tablet with Rugged Frame
– Zebra ET45 10″ Tablet with Rugged Frame
– Zebra ET40 10″ Tablet with Rugged Frame
– Zebra ET45 10″ Tablet with Rugged Frame
SPECIFICHE PRODOTTO
– Product Weight: 2.43 lb
– Hardware Included: (1) Side bracket for accessory mounting|(4) #8-32 x 5/8? Machine Screws|(2) #8-32 x 1/2? Machine Screws|(6) #8-32 Nylock Nuts|(4) #10-24 x 5/8? Machine Screws|(4) #10-24 Nylock Nuts|(2) Small Cable Ties
– Hole Pattern: 75 x 75mm VESA|4-Hole AMPS: 1.181″ x 1.496″
– Materials: High strength composite
– Packaging Type: Poly Bag
– Output Voltage: 5V – 20V @ 3A
– Power Output: 60W
– Input Connector: USB Type-C
– Input Cable Length: 215mm
– Output Connector: USB 2.0 Type A
– Output Cable Length: 215mm
– Transfer Speed: 12Mbps
– Certifications: RoHS|WEEE|CE|UKCA
– Product Weight: 2.43 lb
– Hardware Included: (1) Side bracket for accessory mounting|(4) #8-32 x 5/8? Machine Screws|(2) #8-32 x 1/2? Machine Screws|(6) #8-32 Nylock Nuts|(4) #10-24 x 5/8? Machine Screws|(4) #10-24 Nylock Nuts|(2) Small Cable Ties
– Hole Pattern: 75 x 75mm VESA|4-Hole AMPS: 1.181″ x 1.496″
– Materials: High strength composite
– Packaging Type: Poly Bag
– Output Voltage: 5V – 20V @ 3A
– Power Output: 60W
– Input Connector: USB Type-C
– Input Cable Length: 215mm
– Output Connector: USB 2.0 Type A
– Output Cable Length: 215mm
– Transfer Speed: 12Mbps
– Certifications: RoHS|WEEE|CE|UKCA
CARATTERISTICHE PRODOTTO
– Form-fit + single USB Type-A dock designed specifically for the Zebra ET40 & ET45 10″ tablets with IntelliSkin protective sleeve, featuring GDS Technology
– When connected to a power source via USB Type-C connector, integrated pogo pins provide power to the IntelliSkin-wrapped ET4x while docked
– Space in the back of the dock to accommodate tablet add-ons such as the Expansion Back, PowerPack Battery, and GDS Ergo accessories
– Built-in 2-hole mounting plate for additional device mounting such as a phone; compatible with RAM 2-hole diamond bases and accessory side bracket
– Backed by a 3-year warranty
– Form-fit + single USB Type-A dock designed specifically for the Zebra ET40 & ET45 10″ tablets with IntelliSkin protective sleeve, featuring GDS Technology
– When connected to a power source via USB Type-C connector, integrated pogo pins provide power to the IntelliSkin-wrapped ET4x while docked
– Space in the back of the dock to accommodate tablet add-ons such as the Expansion Back, PowerPack Battery, and GDS Ergo accessories
– Built-in 2-hole mounting plate for additional device mounting such as a phone; compatible with RAM 2-hole diamond bases and accessory side bracket
– Backed by a 3-year warranty
| Linea Prodotto | GDS Tech |
|---|---|
| Marca | Zebra |
| Device | Tablet |
